Cisco Catalyst CW9800H1 - Front View

DescriptionFeature
3 built-in EPA
• Built-in Bay 0: Cisco Catalyst CW9800H1
Wireless Controller and Cisco Catalyst
CW9800H2 Wireless Controller: 8X1 GE or 10
GE SFP interfaces.
• Built-in Bay 1: Cisco Catalyst CW9800H1
Wireless Controller: 3X25 GE SFP interfaces
and Cisco Catalyst CW9800H2 Wireless
Controller: 2X40 GE QSFP interfaces.
• Built-in Bay 2:Cisco Catalyst CW9800H1
Wireless Controller: 1X25 GE SFP interface.
Ethernet Port Adapter (EPA)
One 1 GE RJ-45 or 1 (1 GB or 10 GB) SFP port.Redundancy Ports
One RJ-45 or one micro-USB console portConsole Port
1 service port (one RJ-45)Service Ports
• Cisco Catalyst CW9800H1 Wireless Controller:
Supports four 25 GE ports.
• Cisco Catalyst CW9800H2 Wireless Controller:
Supports two 40 GE ports.
Data Ports
Two USB 3.0 portsUSB
41° to 104° F (5° to 40° C)Operating Temperature
41° to 122° F (5° to 50° C)Short-term operating temperature
5 to 85% non-condensingNominal Operating Humidity
5% to 90% non-condensingShort-term Operating Humidity
–4° to 158° F (–20° to +70° C)Storage temperature
0 to 10,000 feet (0 to 3000 meters).Operational Altitude
See Chapter 2: Supported Hardware Components
for information on supported FRUs.
Field-replaceable units (FRU).
Front View
The following figures show the front view of the Cisco Catalyst CW9800H1 Wireless Controller and Cisco
Catalyst CW9800H2 Wireless Controller.
Cisco Catalyst CW9800H1 and CW9800H2 Wireless Controllers Hardware Installation Guide
2
Overview
Front View
