CHAPTER 4
Installing the Controller
This chapter provides procedures for installing the controller on an equipment shelf, tabletop, or in an equipment
rack.
• Installation Methods, on page 49
• Guidelines for a Standalone Equipment Shelf or Tabletop Installation, on page 50
• Installing the Controller on a Standalone Equipment Shelf or Tabletop, on page 50
• Guidelines for Rack Installation, on page 51
• Attaching Front Rack-Mount Brackets, on page 52
• Mounting the Controller in the Rack, on page 53
• Attaching the Cable Management Bracket, on page 55
• Chassis Ground Connection, on page 55
• Connecting Cables, on page 57
• Management Ethernet Port Cable Connection, on page 58
Installation Methods
The controller is designed for standalone, 2-rail 19-inch rack-mount (front rail only), and 4-rail 19-inch
rack-mount (front and rear rail) installations.
Although rack-mounting is the preferred method of installation, you can mount the chassis on an equipment
shelf or tabletop.
Read the installation instructions before using, installing or connecting the system to the power source.
Statement 1004
Warning
Proceed with the installation, if you have already unpacked your chassis and read all the site requirements for
your new equipment.
