MaximumMinimumEnvironmental Characteristic
122° F (50° C)32° F (0° C)Thermal Shock - Operating at 2.5°
C per minute
Physical Characteristics
Be familiar with the physical characteristics of the Cisco Catalyst CW9800H1 and CW9800H2 Wireless
Controllers to assist you in placing the system at a proper location.
For information regarding rack widths supported for the controller, see the following sections:
• General Rack-Selection Guidelines
• Guidelines for 23-in. (Telco) Racks
Note
The following table shows the weight and dimensions of both the Cisco Catalyst CW9800H1 and CW9800H2
Wireless Controllers:
Table 13: Physical Characteristics of the Cisco Catalyst CW9800H1 and CW9800H2 Wireless Controllerss
Cisco Catalyst CW9800H1 and CW9800H2 Wireless
Controllers
Characteristic
Height—1.73 in. (43.94 mm)—1RU; rack-mount per
EIA RS-310
Height
Width—17.5 in. (444.5 mm)Width
Depth—24.02 in. (610.11 mm) including card handles,
cable-management brackets, and power supply
handles.
Depth
23 lb (10.45 kg) fully loadedWeight
The following list describes additional characteristics:
• Chassis height meets EIA-310 rack spacing, universal rack mount
• Cisco Catalyst CW9800H1 and CW9800H2 Wireless Controllers—1RU (1.73 in or 43.94 mm)
• Chassis width meets EIA-310 19 in. (17.5 in. or 444.5 mm) wide with rack brackets
• Cable-management brackets allow a bend radius of 1.5 in. (38.1 mm) for cables
• Ships with forward rack-mount brackets installed and an extra set included in the accessory kit
Cisco Catalyst CW9800H1 and CW9800H2 Wireless Controllers Hardware Installation Guide
35
Preparing Your Site for Installation
Physical Characteristics
