Table 12: Access Point PoE In Ethernet Connector Pinouts
Signal NamePin
Number
Ethernet signal pair (10/100/1000BASE-T) and VDC1
2
Ethernet signal pair (10/100/1000BASE-T) and VDC
3
6
Ethernet signal pair (1000BASE-T) and VDC
4
5
Ethernet signal pair (1000BASE-T) and VDC
7
8
Chassis ground
Shield
The following table describes the pin signals for the power injector input connector (To Switch).
Table 13: Power Injector AIR-PWRINJ-60RGD1= and AIR-PWRINJ-60RGD2= Input Connector (To Switch) Pinouts
Signal NamePin
Number
Ethernet signal pair (10/100/1000BASE-T)1
2
Ethernet signal pair 10/100/1000BASE-T)
3
6
Ethernet signal pair (1000BASE-T)
4
5
Ethernet signal pair (1000BASE-T)
7
8
Chassis ground
Shield
The following table describes the RJ-45 pin signals for the power injector output connector (To AP).
