Table 14: Power Injector AIR-PWRINJ-60RGD1= and AIR-PWRINJ-60RGD2= Output Connector (To AP) Pinouts
Signal NamePin
Number
Ethernet signal pair (10/100/1000BASE-T) and 55 VDC return1
2
Ethernet signal pair (10/100/1000BASE-T) and 55 VDC (+)
3
6
Ethernet signal pair (1000BASE-T) and 55 VDC (+)
4
5
Ethernet signal pair (1000BASE-T) and 55 VDC return
7
8
Chassis ground
Shield
The power injector output connector (To AP) only supplies 55 VDC power when the Ethernet cable is connected
to the IW6300 PoE IN connector.
Note
