3-11
Cisco Content Delivery Engine 205/220/250/280/285/420/460/475 Hardware Installation Guide
Chapter 3 Installing the Content Delivery Engines
Installing the CDEs
Figure 3-8 Power Supply Release Tab on a CDE205, and CDE220,
Figure 3-9 Power Supply Release Tab on a CDE420
Step 4
Pull the power supply out using the handle on the front of the power supply (see Figure 3-10).
1 Power supply 2 Release tab
204337
2
1
1 Power supply 2 Release tab
