3-29
Cisco Content Delivery Engine 205/220/250/280/285/420/460/475 Hardware Installation Guide
Chapter 3 Installing the Content Delivery Engines
Installing the CDEs
Figure 3-27 Attaching the Inner Rails to the Middle and Outer Rails
Step 9
Depress the locking tabs on both sides of the chassis simultaneously and push the chassis all the way
into the rear of the rack.
Step 10 If additional security is required, secure the chassis handles to the front of the rack with two screws
(optional).
1 Outer rail assembly 2 Inner rail assembly
3 Middle rail assembly 4 Ball bearing shuttle
209591
3
1
2
4
