3-28
Cisco Content Delivery Engine 205/220/250/280/285/420/460/475 Hardware Installation Guide
Chapter 3 Installing the Content Delivery Engines
Installing the CDEs
Figure 3-26 Extending the Rev. B Rails
Step 8 Pull the middle rail out of the front of the outer rail and make sure the ball bearing shuttle is locked at
the front of the middle rail. Align the inner rail with the middle rail and then push evenly on both sides
of the chassis until it clicks into the fully extended position.
1 Outer rail assembly 2 Middle rail assembly
209590
1
2
