Cisco Content Delivery Engine 205/220/250/280/285/420/460/475 Hardware Installation Guide
Chapter 1 Overview of the Content Delivery Engines
Hardware Features
CDE250 Hardware Overview
The CDE250 ships with the following components installed:
• 2 Quad Core Intel Xeon (Westmere) CPUs @ 2.4GHz
• 4 Onboard Gigabit Ethernet NICs (see Table 1-6 for NIC information for the various CDE250
models)
• 2 x Dual 10GE NIC ports in slots 2 and 6, and 10GE Ports support Copper and Fiber SFP Media
Modules
• 2 hot-swappable power supplies
• 1 x 8-GB CF + IDE adapter physically attached as IDE primary master
• 3 external SAS disk controllers located in slots 1, 3, and 4
• 1 internal MegaRAID SAS disk controller located in slot 5
• Storage drives mounted internally (see Table 1-6 for specific drive information for the various
CDE250 models)
Table 1-6 shows the supported CDE250 configurations.
CDE220 2G2-C CB-16-12A500-2QTX 12 500-GB
SATA
16 GB Dense IS
Streamer,
Service Router,
or Content
Acquirer
VDS-IS 3.0 2 Quad (8 GE) Copper
CDE220 2G2-F CB-16-12A500-4DSX 12 500-GB
SATA
16 GB Dense IS
Streamer
Service Router,
or Content
Acquirer
VDS-IS 3.0 4 Dual (8 GE) Fiber
CDE220 2S1-C
1
CB-16-4F160-1QTX 4 160-GB SSD 16 GB Entry-level TV
Streamer
CDS-TV 3.0 1 Quad (4 GE) Copper
CDE220 2S1-F
1
CB-16-4F160-2DSX 4 160-GB SSD 16 GB Entry-level TV
Streamer
CDS-TV 3.0 2 Dual (4 GE) Fiber
CDE220 2S3-C
1
CB-32-12F160-3QTX 12 160-GB
SSD
32 GB Dense TV
Streamer
CDS-TV 3.0 3 Quad (12 GE)
Copper
CDE220 2S3-F
1
CB-32-12F160-4DSX 12 160-GB
SSD
32 GB Dense TV
Streamer
CDS-TV 3.0 4 Dual (8 GE) Fiber
CDE220 2S3I-C
1
CB-32-12FI160-3QTX 12 160-GB
SSD
32 GB Dense IS
Streamer
VDS-IS 3.0 3 Quad (12 GE)
Copper
CDE220 2S3I-F
1
CB-32-12FI160-4DSX 12 160-GB
SSD
32 GB Dense IS
Streamer
VDS-IS 3.0 4 Dual (8 GE) Fiber
1. Featuring Flash Solid State Drive (SSD) technology.
Table 1-5 Supported CDE220 Configurations (continued)
CDE PID Drives RAM Product Name
Hardware
Support
First
Introduced NIC
