Cisco CDE 220 Series User Manual

1-56
Cisco Content Delivery Engine 205/220/250/280/285/420/460/475 Hardware Installation Guide
Chapter 1 Overview of the Content Delivery Engines
Hardware Features
In Table 1-52, read the status and fault LED states together in each row to determine the event that cause
this combination.
Table 1-51 CDE280 Rear Panel LEDs, Definition of States
LED Name State
1 Power supply fault
This is a summary; for advanced
power supply LED information,
see Table 1-52.
• Off—The power supply is operating normally.
• Amber, blinking—An event warning threshold has been
reached, but the power supply continues to operate.
• Amber, solid—A critical fault threshold has been
reached, causing the power supply to shut down (for
example, a fan failure or an over-temperature
condition).
2 Power supply status
This is a summary; for advanced
power supply LED information,
see Table 1-52.
AC power supplies:
• Off—There is no AC power to the power supply.
• Green, blinking—AC power OK; DC output not
enabled.
• Green, solid—AC power OK; DC outputs OK.
DC power supplies:
• Off—There is no DC power to the power supply.
• Green, blinking—DC power OK; DC output not
enabled.
• Green, solid—DC power OK; DC outputs OK.
4 1-Gb Ethernet dedicated
management link speed
• Off—Link speed is 10 Mbps.
• Amber—Link speed is 100 Mbps.
• Green—Link speed is 1 Gbps.
5 1-Gb Ethernet dedicated
management link status
• Off—No Link is present.
• Green—Link is active.
• Green, blinking—Traffic is present on the active link.
6 1-Gb Ethernet link speed
• Off—Link speed is 10 Mbps.
• Amber—Link speed is 100 Mbps.
• Green—Link speed is 1 Gbps.
7 1-Gb Ethernet link status
• Off—No link is present.
• Green—Link is active.
• Green, blinking—Traffic is present on the active link.
8 Unit Identification
• Off—The unit identification function is not in use.
• Blue—The unit identification function is activated.
