Cisco Content Delivery Engine 205/220/250/280/285/420/460/475 Hardware Installation Guide
Chapter 1 Overview of the Content Delivery Engines
Hardware Features
Rear Panels LEDs and Buttons
Figure 1-49 shows the CDE280 rear panel LEDs and buttons. Table 1-51 defines the LED states.
Figure 1-49 CDE280 Rear Panel LEDs and Buttons
1 Power supply fault LED 6 1-Gb Ethernet link speed LED
2 Power supply AC status LED 7 1-Gb Ethernet link status LED
4 1-Gb Ethernet dedicated management link
speed LED
8 Unit Identification button/LED
5 1-Gb Ethernet dedicated management link
status LED
