Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Audio Input Microphone [1..2]/[1..4] VideoAssociation MuteOnInactiveVideo
NOTE: Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
Enable association of a video source to a microphone audio input.
Requires user role: ADMIN
Value space: <On/Off>
On: A video source is associated, and the audio will be muted if the associated video source is
not displayed.
Off: No video source is associated.
Example: Audio Input Microphone 1 VideoAssociation MuteOnInactiveVideo: On
Audio Input Microphone [1..2]/[1..4] VideoAssociation VideoInputSource
NOTE: Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
Select the associated video input source.
Requires user role: ADMIN
Value space: <1/2/3>
Range: Select one of the video input sources.
Example: Audio Input Microphone 1 VideoAssociation VideoInputSource: 1
Audio Input Microphone [1..2]/[1..4] Level
NOTE: Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
Define the audio level of the Microphone input connector, in steps of 1 dB.
See the Audio Level tables in the Physical Interfaces Guide for the codec for a complete overview
of the values represented in dB.
Requires user role: ADMIN
Value space: <0..24>
Range: Select a value from 0 to 24 dB.
Example: Audio Input Microphone 1 Level: 15
Audio Input Microphone [1..2]/[1..4] Mode
NOTE: Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
Set the audio input microphone mode.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the microphone connector.
Off: Disable the microphone connector.
Example: Audio Input Microphone 1 Mode: On
Audio Input Microphone [1..2]/[1..4] Type
NOTE: Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
The microphone connectors are intended for electret type microphones. The microphone
connector can be set to line or microphone mode.
Requires user role: ADMIN
Value space: <Microphone/Line>
Microphone: Select Microphone when you have 48 V Phantom voltage and the pre-amplification
is On.
Line: Select Line when you have a standard balanced line input. The phantom voltage and pre-
amplification is Off.
Example: Audio Input Microphone 1 Type: Line
Audio Output HDMI [1] Level
Define the output level of the HDMI output connector, in steps of 1 dB.
See the Audio Level tables in the Physical Interfaces Guide for the codec for a complete overview
of the menu values represented in dB.
Requires user role: ADMIN
Value space: <-24..0>
Range: Select a value from -24 to 0dB.
Example: Audio Output HDMI 1 Level: 0
Audio Output HDMI [1] Mode
Determine if the audio channel on the HDMI output connector shall be enabled.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the audio channel on the HDMI output.
Off: Disable the audio channel on the HDMI output.
Example: Audio Output HDMI 1 Mode: On
Audio Output Line [1..2] Channel
Define whether the Audio Line output is a mono signal or part of a multichannel signal.
Requires user role: ADMIN
Value space: <Left/Right/Mono>
Left: The Audio Line output signal is the left channel of a stereo signal.
Right: The Audio Line output signal is the right channel of a stereo signal.
Mono: The Audio Line output signal is a mono signal.
Example: Audio Output Line 1 Channel: left
