Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Codec C60/C40
UNIT DELIVERED COMPLETE WITH:
Video conferencing codec, wireless remote control,
rack mounting rails (C60), rack mounting ears (C40),
LAN cable, power cable
BANDWIDTH
H.323/SIP up to 6 Mbps point-to-point
H.323/SIP up to 10 Mbps total MultiSite bandwidth*
FIREWALL TRAVERSAL
Cisco TelePresence Expressway technology
H.460.18, H.460.19 Firewall Traversal
VIDEO STANDARDS
H.261, H.263, H.263+, H.264
VIDEO FEATURES
Native 16:9 Widescreen
Advanced Screen Layouts
Intelligent Video Management
Local Auto Layout
7 embedded individual video compositors — 1 for every
output and 1 for every encoder (C60 only) **
VIDEO INPUTS (5 INPUTS (C60) / 4 INPUTS (C40))
2 × HDMI inputs, supported formats:
1920 × 1080@60, 59.94 Hz (1080p60)
1920 × 1080@50 Hz (1080p50)
1920 × 1080@30, 29.97 Hz (1080p30)
1920 × 1080@25 Hz (1080p25)
1920 × 1080@24, 23.97 Hz (1080p24)
1280 × 720@60, 59.94 Hz (720p60)
1280 × 720@50 Hz (720p50)
720 × 480@60, 59.94 Hz (480p60)
640 × 480@60 Hz (480p60)
1600 × 1200@50, 60 Hz (UXGA)
1280 × 1024@60, 75 Hz (SXGA)
1024 × 768@60, 70, 75, 85 Hz (XGA)
800 × 600@56, 60, 72, 75, 85 Hz (SVGA)
1920 × 1200@50, 60 Hz (WUXGA)
1680 × 1050@60 Hz (WSXGA+)
1440 × 900@60 Hz (WXGA+)
1280 × 768@60 Hz (WXGA)
2 (C60), 1 (C40) × DVI-I inputs, supported
formats:
Analog (VGA):
1920 × 1080@60 Hz (1080p60)
1280 × 720@60 Hz (720p60)
1600 × 1200@60 Hz (UXGA)
1280 × 1024@60, 75 Hz (SXGA)
1280 × 960@60 Hz
1024 × 768@60, 70, 75, 85 Hz (XGA)
1920 × 1200@50 Hz (WUXGA)
1680 × 1050@60 Hz (WSXGA+)
1440 × 900@60 Hz (WXGA+)
1280 × 800@60 Hz (WXGA)
1280 × 768@60 Hz (WXGA)
Analog (YPbPr):
1920 × 1080@60 Hz (1080p60)
1920 × 1080@50 Hz (1080p50)
1920 × 1080@30 Hz (1080p30)
1920 × 1080@25 Hz (1080p25)
1280 × 720@60 Hz (720p60)
1280 × 720@50 Hz (720p50)
1280 × 720@30 Hz (720p30)
720 × 576@50 Hz (576p50)
720 × 480@60 Hz (480p60)
Digital (DVI-D):
Same as HDMI, ref. above.
1 × S-video/Composite input (BNC connector):
PAL/NTSC
Extended Display Identification Data (EDID)
VIDEO OUTPUTS (3 OUTPUTS (C60) /
2 OUTPUTS (C40))
1 × HDMI output, 1 × DVI-I output, supported
formats:
1920 × 1080@60 Hz (1080p60)
1280 × 720@60 Hz (720p60)
1600 × 1200@60 Hz (UXGA)
1280 × 1024@60 Hz (SXGA)
1024 × 768@60 Hz (XGA)
800 × 600@60 Hz (SVGA)
640 × 480@60 Hz (VGA)
1920 × 1200@60Hz (WUXGA)
1360 × 768@60 Hz
1366 × 768@60 Hz
1280 × 768@60 Hz (WXGA)
1 × Composite output (BNC connector) (C60 only):
PAL/NTSC
VESA Monitor Power Management
Extended Display Identification Data (EDID)
LIVE VIDEO RESOLUTIONS (ENCODE/DECODE)
176 × 144@30 fps (QCIF)
352 × 288@30 fps (CIF)
512 × 288@30 fps (w288p)
576 × 448@30 fps (448p)
768 × 448@30 fps (w448p)
704 × 576@30 fps (4CIF)
1024 × 576@30 fps (w576p)
1280 × 720@30 fps (720p30)
1920 × 1080@30 fps (1080p30)*
640 × 480@30 fps (VGA)
800 × 600@30 fps (SVGA)
1024 × 768@30 fps (XGA)
1280 × 1024@30 fps (SXGA) (C60 only)
1280 × 768@30 fps (WXGA)
1440 × 900@30 fps (WXGA+)* (C60 only)
1680 × 1050@30 fps (WSXGA+)* (C60 only)
1600 × 1200@30 fps (UXGA)* (C60 only)
1920 × 1200@25fps (WUXGA)* (C60 only)
512 × 288@60 fps (w288p60)*
768 × 448@60 fps (w448p60)*
1024 × 576@60 fps (w576p60)*
1280 × 720@60 fps (720p60)*
720p30 from 768kbps
720p60 from 1152kbps*
1080p30 from 1472 kbps*
AUDIO STANDARDS
G.711, G.722, G.722.1, 64 kbps & 128 kbps MPEG4
AAC-LD, AAC-LD Stereo
AUDIO FEATURES
CD-Quality 20 KHz Mono and Stereo
Four (C60) / Two (C40) separate acoustic echo
cancellers
4-port (C60) / 2-port (C40) Audio mixer
Automatic Gain Control (AGC)
Automatic Noise Reduction
Active lip synchronization
AUDIO INPUTS (7 INPUTS (C60), 5 INPUTS
(C40))
4 × microphone (C60) , 2 × microphone (C40) ,48 V
phantom powered, XLR connector each with separate
echo cancellers and noise reduction,all microphones
can be set for balanced line level
2 × RCA/Phono, Line Level: Stereo PC input,
configurable to 2 × RCA/Phono, Line Level: Mono
auxiliary/DVD input
1 × HDMI, digital: Stereo PC/DVD inputs
AUDIO OUTPUTS (3 OUTPUTS)
2 × RCA/Phono, line level, stereo main audio,
configurable to S/PDIF or 2 × RCA/Phono, line level,
mono to recording device
1 × HDMI, digital, stereo main audio
DUAL STREAM
H.239 (H.323) dual stream
BFCP (SIP) dual stream
Support for resolutions up to 1080p30/WUXGA
(C60)/ WXGAp30 (C40), independent of main stream
resolution
Technical specifications
