Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Network [1..1] IPv4 Address
Enter the static IPv4 network address for the system. Only applicable if the Network Assignment is
set to Static.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: Only the valid IP address format is accepted. An IP address that contains letters
(192.a.2.0) or unvalid IP addresses (192.0.1234.0) will be rejected.
Example: Network 1 IPv4 Address: "192.0.2.0"
Network [1..1] IPv4 Gateway
Define the IPv4 network gateway. Only applicable if the Network Assignment is set to Static.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: Compact string with a maximum of 64 characters.
Example: Network 1 IPv4 Gateway: "192.0.2.0"
Network [1..1] IPv4 SubnetMask
Define the IPv4 network subnet mask. Only applicable if the Network Assignment is set to Static.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: Compact string with a maximum of 64 characters.
Example: Network 1 IPv4 SubnetMask: "255.255.255.0"
Network [1..1] IPv6 Address
Enter the static IPv6 network address for the system. Only applicable if the Network IPv6
Assignment is set to Static.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: The IPv6 address of host name.
Example: Network 1 IPv6 Address: "ffff:ffff:ffff:ffff:ffff:ffff:ffff:ffff"
Network [1..1] IPv6 Gateway
Define the IPv6 network gateway address. Only applicable if the Network IPv6 Assignment is set to
Static.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: The IPv6 address of host name.
Example: Network 1 IPv6 Gateway: "ffff:ffff:ffff:ffff:ffff:ffff:ffff:ffff"
Network [1..1] IPv6 Assignment
Define whether to use Autoconf or Static IPv6 assignment.
Requires user role: ADMIN
Value space: <Static/Autoconf>
Static: Set the network assignment to Static and configure the static IPv6 settings (IP Address
and Gateway).
Autoconf: Enable IPv6 stateless autoconfiguration of the IPv6 network interface. See RFC4862
for a detailed description.
Example: Network 1 IPv6 Assignment: Autoconf
Network [1..1] IPv6 DHCPOptions
Retrieves a set of DHCP options from a DHCPv6 server.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the retrieval of a selected set of DHCP options from a DHCPv6 server.
Off: Set to Off when IPv6 Assignment is set to Static.
Example: Network 1 IPv6 Gateway: On
Network [1..1] QoS Mode
The QoS (Quality of Service) is a method which handles the priority of audio, video and data in
the network. The QoS settings must be supported by the infrastructure. Diffserv (Differentiated
Services) is a computer networking architecture that specifies a simple, scalable and coarse-
grained mechanism for classifying, managing network traffic and providing QoS priorities on
modern IP networks.
Requires user role: ADMIN
Value space: <Off/Diffserv>
Off: No QoS method is used.
Diffserv: When you set the QoS Mode to Diffserv you must configure the Diffserv sub menu
settings (Audio, Data, Signalling and Video).
Example: Network 1 QoS Mode: diffserv
Network [1..1] QoS Diffserv Audio
The Diffserv Audio defines which priority Audio packets should have in an IP network. Enter a
priority, which ranges from 0 to 63 for the packets. The higher the number, the higher the priority.
These priorities might be overridden when packets are leaving the network controlled by the local
network administrator. NOTE: Requires the Network QoS Mode to be set to Diffserv.
Requires user role: ADMIN
Value space: <0..63>
Audio: A recommended value is Diffserv Code Point (DSCP) AF41, which equals the value 34. If
in doubt, contact your network administrator.
Range: Select a value from 0 to 63.
Example: Network 1 QoS Diffserv Audio: 0
