Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Video Monitors
Set the monitor layout mode.
Requires user role: ADMIN
Value space: <Single/Dual/DualPresentationOnly>
Single: The same layout is shown on all monitors.
Dual: The layout is distributed on two monitors.
DualPresentationOnly: All participants in the call will be shown on the first monitor, while the
presentation (if any) will be shown on the second monitor.
Example: Video Monitors: Single
Video OSD Mode
The Video OSD (On Screen Display) Mode lets you define if information and icons should be
displayed on screen.
Requires user role: ADMIN
Value space: <On/Off>
On: Display the on screen menus, icons and indicators.
Off: Hide the on screen menus, icons and indicators.
Example: Video OSD Mode: On
Video OSD AutoSelectPresentationSource
Determine if the presentation source should be automatically selected.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable automatic selection of the presentation source.
Off: Disable automatic selection of the presentation source.
Example: Video OSD AutoSelectPresentationSource: Off
Video OSD TodaysBookings
This setting can be used to display the systems bookings for today on the main OSD menu. This
requires that the system is bookable by an external booking system, like Cisco TelePresence
Management Suite (TMS).
Requires user role: ADMIN
Value space: <On/Off>
On: Displays information about this systems bookings on screen.
Off: Do not display todays bookings.
Example: Video OSD TodaysBookings: Off
Video OSD MyContactsExpanded
Set how the local contacts will be displayed in the phone book dialog in the OSD (On Screen
Display).
Requires user role: ADMIN
Value space: <On/Off>
On: The local contacts in the phone book will be shown in the top level of the phonebook dialog.
Off: The local contacts will be placed in a separate folder called MyContacts in the phonebook
dialog.
Example: Video OSD MyContactsExpanded: Off
Video OSD Output
The Video OSD (On Screen Display) Output lets you define which monitor should display the on
screen menus, information and icons. By default the OSD is sent to the monitor connected to the
Video OSD Output 1. If you cannot see the OSD on screen, then you must re-configure the OSD
Output. You can do this by entering a key sequence on the remote control, from the web interface,
or by a command line interface.
Using the remote control: Press the Disconnect key followed by: * # * # 0 x # (where x is output 1
to 2).
Using the web interface: Open a web browser and enter the IP address of the codec. Open the
Advanced Configuration menu and navigate to Video OSD Output and select the video output.
Using a command line interface: Open a command line interface and connect to the codec (if in
doubt of how to do this, see the API Guide for the codec). Enter the command: xConfiguration
Video OSD Output [1..2] (select the OSD Output)
Requires user role: ADMIN
Value space: <1..2>
Range: Select 1 for HDMI 1 output, or select 2 for DVI-I 2 output.
Example: Video OSD Output: 1
Video OSD InputMethod InputLanguage
The codec can be enabled for Cyrillic input characters in the menus on screen. NOTE: Requires
that xConfiguration Video OSD inputMethod Cyrillic is set to On.
Requires user role: ADMIN
Value space: <Latin/Cyrillic>
Latin: Latin characters can be entered when using the remote control (default).
Cyrillic: Cyrillic characters can be entered using the remote control. NOTE: Requires a Cisco
TelePresence Remote Control with Cyrillic fonts.
Example: Video OSD InputMethod InputLanguage: Latin
