Cisco IP Video Phone E20 Administrator guide
D143 30.12 Administrator guide Cisco IP Video Phone E20, TE4.1 November 2011.
All contents are Copyright © 2010–2011, Cisco Systems, Inc. All rights reserved.
Description of the Advanced settings
On the following pages you will nd a list of the settings available to
administrators—known as the Advanced settings.
We recommend that you visit the Cisco web site regularly for updated versions
of the manual. Go to: http://www.cisco.com/go/telepresence/docs.
To access the Advanced settings, do as follows:
1. Press the
key to produce the menu. Use the key to navigate to the
Menu tab and then down to Advanced settings and press .
2. To navigate further down in the menu hierarchy, press the key. On this
level do not use the right arrow
key to navigate to the right, this will
take you to the next menu tab (new in this version). However, for lower levels
(further down in the menu hierarchy) using the right arrow
key to navigate
to the right to expand a menu item will work as usual.
3. To go one or more steps back in the hierarchy, use the
key to navigate to
the left, the required number of times.
4. To collapse all menus, press the
key.
5. To put a change into eect, press
as soon as the required setting has been
selected or changed.
IP settings
This menu lets you
• Set IP assignment to Static or DHCP
When set to Static, you should also dene:
• IP address
• Subnet mask
• Gateway
System conguration
All items in this menu are expandable whenever they have a sign to their left.
To expand a menu item press the right arrow
key to navigate to the right.
All items in a menu item are collapsible whenever they have a
sign to their left.
To collapse a menu press the left arrow
key to navigate to the left.
Audio
The settings found here let you specify ring tone, ring volume, whether key
tones should be audible or not and the volume of the handset, headset and the
speaker. The three latter may be set individually.
Volume
Handset volume can be set to 0–100 in steps of 5.
Headset volume can be set to 0–100 in steps of 5.
Speaker volume can be set to 0–100 in steps of 5.
All these may be set individually (independent of each other).
SoundsAndAlert
Key tones let you determine whether you should hear a sound every time
you press a key or not. Set to On to activate.
Ring tones allow you to select between the ring tones available. Use the
key to navigate up and down as usual. You will hear the dierent ring
tones as you move up and down.
Ring volume lets you set the volume of the incoming call signal. You will
hear the level as you adjust.
Camera 1
Brightness can be set to Auto or Manual which can be anywhere in the
range 1–20 in steps of 1.
Whitebalance can be set to Auto or Manual which can be anywhere in
the range 1–32 in steps of 2.
CapsetFilterDebug
Can be set to solve interoperability issues when used with non-Cisco
devices. Contact your local Cisco representative.
