Connecting the E20
Connect the cables as shown. If you have one LAN connection only, and need
that for your PC, the E20 has a built in Gigabit ethernet switch that enables you to
connect your PC to the E20 to access the LAN through the E20.
Power supply HandsetLocal area network (LAN)
Optional PC
connection
Optional telephone style
headset connection
Attach USB
stick with
images for
screen saver
