Advanced conguration
Video Layout ScaleToFrame
Dene what to do if the aspect ratio of a video input source doesn't match the aspect ratio of the
corresponding image frame in a composition. For example if you have a 4:3 input source (like XGA) to
be displayed on a 16:9 output (like HD720).
Requires user role: ADMIN
Value space: <Manual/MaintainAspectRatio/StretchToFit>
Manual: If the dierence in aspect ratio between the video input source and the target image
frame is less than the ScaleToFrameThreshold conguration (in percent), the image is stretched to
t. If not, the system will maintain the original aspect ratio.
MaintainAspectRatio: Will maintain the aspect ratio of the input source, and ll in black in the rest
of the frame (letter boxing or pillar boxing).
StretchToFit: Will stretch (horizontally or vertically) the input source to t into the image frame.
Ex a m ple: Video Layout ScaleToFrame: MaintainAspectRatio
Video Layout ScaleToFrameThreshold
Only applicable if the ScaleToFrame conguration is set to manual. If the dierence in aspect ratio
between the video input source and the target image frame is less than the ScaleToFrameThreshold
conguration (in percent), the image is stretched to t. If not, the system will maintain the original
aspect ratio.
Requires user role: ADMIN
Value space: <0..100>
Range: Select a value from 0 to 100 percent.
Ex a m ple: Video Layout ScaleToFrameThreshold: 5
Video Layout LocalLayoutFamily
Select which video layout family to be used locally.
Requires user role: ADMIN
Value space: <Auto/FullScreen/Equal/PresentationSmallSpeaker/PresentationLargeSpeaker>
Auto: The default layout family, as given by the layout database, will be used as the local layout.
For more information about the layout database, see the command: xCommand Video Layout
LoadDb.
FullScreen: The FullScreen layout family will be used as the local layout.
Equal: The Equal layout family will be used as the local layout.
PresentationSmallSpeaker: The PresentationSmallSpeaker layout family will be used as the local
layout.
PresentationLargeSpeaker: The PresentationLargeSpeaker layout family will be used as the local
layout.
Ex a m ple: Video Video Layout LocalLayoutFamily: Auto
Video Layout RemoteLayoutFamily
Select which video layout family to be used for the remote participants.
Requires user role: ADMIN
Value space: <Auto/FullScreen/Equal/PresentationSmallSpeaker/PresentationLargeSpeaker>
Auto: The default layout family, as given by the local layout database, will be used as the remote
layout. For more information about the layout database, see the command: xCommand Video
Layout LoadDb.
FullScreen: The FullScreen layout family will be used as the remote layout.
Equal: The Equal layout family will be used as the remote layout.
PresentationSmallSpeaker: The PresentationSmallSpeaker layout family will be used as the
remote layout.
PresentationLargeSpeaker: The PresentationLargeSpeaker layout family will be used as the
remote layout.
Ex a m ple: Video Video Layout RemoteLayoutFamily: Auto
Video OSD Mode
Not applicable in this version.
Video OSD TodaysBookings
Not applicable in this version.
Video OSD MyContactsExpanded
Not applicable in this version.
Video OSD Output
Not applicable in this version.
Video OSD LoginRequired
Not applicable in this version.
Video OSD InputMethod InputLanguage
Not applicable in this version.
Video OSD InputMethod Cyrillic
Not applicable in this version.
The Video settings, cont... The Video settings, cont...

Cisco EX90 Specifications

General

Microphone	Integrated
Speakers	Integrated
Connectivity	Ethernet, Wi-Fi
Video Inputs	HDMI
Audio Inputs	3.5mm
Video Standards	H.264
Audio Standards	G.711, G.722, AAC
Power Supply	Internal power supply
