Troubleshooting
Locating LEDs and Components
Front View
Below is an illustration of the unit's front view and a list of the LEDs and components available.
Figure 3 Front View of the Cisco Expressway Unit
1 HDdrive activity/fault LED
2 Identification button/LED
3 Operational panel buttons and LEDs
4 Power button/power status LED
5 Identification button/LED
6 System status LED
7 Fan status LED
8 Temperature status LED
9 Power supply status LED
10 Network link activity LED
