Preparing to Install
Environmental and Power Specifications
To view environmental and power specifications for the appliance server, see
http://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/c/hw/C220M4/install/C220M4/spec.html.
Note: If migrating from an older appliance, be aware—while efficient once running—the CE1100 is capable of
consuming more power. It has a larger capacity and has greater inrush at power-on. Also, unlike the first-generation
appliance or the CE500, it has two power supplies. Refer to the power specifications for more information.
Unpacking the Unit and Preparing the Installation
See http://www.cisco.com/en/US/docs/unified_computing/ucs/c/hw/C220/install/install.html for information on:
■ Unpacking and inspecting the server.
The CE1100 is shipped with 2 x 10 Gb fiber SFPs and 2 x 1 Gb copper SFPs.
■ Installation guidelines.
■ Rack requirements.
■ Equipment requirements.
■ Slide rail adjustment range.
Locating Serial Numbers
The Cisco Expressway appliance displays two serial numbers:
■ UCSserial number:
— Has the format FCHxxxxxxxx.
— Is displayed on the hardware's pull-out tab and in the CIMC web interface.
■ Application/Software serial number:
— Has the format 52DNNNNN, where D indicates the CE1100 series and N are numbers.
— Is displayed in the Cisco Expressway web interface, on the underside of the pull-out tab, and is available in
the SSH session.
— Must be supplied to obtain release and option keys.
7
Cisco Expressway CE1100 Appliance Installation Guide
Preparing to Install
