• If a wireless link is not specified in a Pass list, it will be
assigned the lowest routing priority, but will not be
completely excluded from routing.
3. Example 1: If you want to create a simple Pass list that includes
the link between unit ID numbers 5.2.22.136 and 5.29.252.213
(Figure 36 (page 99)), and give the link routing priority 0 (the
highest possible priority):
• Cell A1 of the *.CSV file would contain the parameter
5.2.22.136,5.29.252.213,0
• Cell A2 of the *.CSV file would contain the parameter
5.29.252.213, 5.2.22.136,0
Figure 36. Sample Pass list (Example 1)
4. Example 2: If you want to create a Pass list that includes the
links between unit ID numbers 5.2.22.136 and 5.29.252.213 (with
routing priority 0), and between unit ID numbers 5.29.252.213
and 5.155.105.128 (with routing priority 1) (Figure 37 (page 99)):
• Cell A1 of the *.CSV file would contain the parameter
5.2.22.136,5.29.252.213,0
• Cell A2 of the *.CSV file would contain the parameter
5.29.252.213, 5.2.22.136,0
• Cell A3 of the *.CSV file would contain the parameter
5.29.252.213,5.155.105.128,1
• Cell A4 of the *.CSV file would contain the parameter
5.155.105.128,5.29.252.213,1
Figure 37. Sample Pass list (Example 2)
5. Example 3: If you want to create a simple Block list that includes
the links between unit ID numbers 5.2.22.136 and 5.29.252.213
(Figure 38 (page 100)):
• Cell A1 of the *.CSV file would contain the parameter
5.2.22.136,5.29.252.213
Device configuration using the configurator interface
© 2021 Cisco and/or its affiliates. All rights reserved. Page 99 of 175
