Cisco HWIC-4ESW and HWIC-D-9ESW EtherSwitch Interface Cards
How to Configure EtherSwitch HWICs
10
Book Title
Enter the show vlan-switch brief command in EXEC mode, using the Cisco IOS CLI to verify that a
VLAN has been deleted from the switch, as shown in the following output example:
Router# show vlan-switch brief
VLAN Name Status Ports
---- -------------------------------- --------- -------------------------------
1 default active Fa0/1/0, Fa0/1/1, Fa0/1/2
Fa0/1/3, Fa0/1/4, Fa0/1/5
Fa0/1/6, Fa0/1/7, Fa0/1/8
300 VLAN0300 active
1002 fddi-default active
1003 token-ring-default active
1004 fddinet-default active
1005 trnet-default active
Router#
Configuring VLAN Trunking Protocol
This section describes how to configure the VLAN Trunking Protocol (VTP) on an EtherSwitch HWIC,
and contains the following tasks:
• Configuring a VTP Server, page 10
• Configuring a VTP Client, page 12
• Disabling VTP (VTP Transparent Mode), page 12
• Verifying VTP, page 13
Note VTP pruning is not supported by EtherSwitch HWICs.
Configuring a VTP Server
When a switch is in VTP server mode, you can change the VLAN configuration and have it propagate
throughout the network.
Follow the steps below to configure the switch as a VTP server.
SUMMARY STEPS
1. enable
2. vlan database
3. vtp server
4. vtp domain domain_name
5. vtp password password_value
6. exit
