37
— 1 stop bit
— No parity
— None (flow control)
9. Connect power to the switch as described in Connecting to Power, page 37.
10. When the PC or terminal displays the bootloader sequence, press Enter to display the setup prompt.
11. Follow the steps in the Completing the Setup Program, page 100.
Connecting to Power
Tools and Equipment
Obtain these necessary tools and equipment:
Ratcheting torque flathead screwdriver that exerts up to 15 in-lb (1.69 N-m) of pressure.
For the protective ground connector, obtain a single or pair of stud size 6 ring terminals (such as Hollingsworth part
number R3456B or equivalent).
Crimping tool (such as Thomas & Bett part number WT2000, ERG-2001, or equivalent).
10-gauge copper ground wire (such as Belden part number 9912 or equivalent).
For DC power connections, use UL- and CSA-rated, style 1007 or 1569 twisted-pair copper appliance wiring
material (AWM) wire (such as Belden part number 9318).
Wire-stripping tools for stripping 10- and 18-gauge wires.
A number-2 Phillips screwdriver.
A flat-blade screwdriver.
Supported Power Supplies
The supported power supplies are listed in Table 11 on page 37.
Table 11 Supported Power Supplies
PWR-IE65W-PC-DC PWR-IE65W-PC-AC PWR-IE50W-AC-IEC PWR-IE50W-AC
Current DC-DC AC-DC AC-DC AC-DC
Input 18-60 VDC/4.3 Amp 110/220 VAC and
88-300 VDC
110/220 VAC 110/220VAC and
88-300 VDC
Output 54VDC/1.2 Amp 54VDC/1.2 Amp 24VDC/2.1Amp 24 VDC / 2.1Amp
Dimensions 5.9inH x 2.1in.W x
4.9 in. D
5.9 in. H x 2.1 in. W x
4.9 in. D
5.8 in. H x 2 in. W x
4.4 in. D
5.8 in. H x 2 in. W x
4.4 in. D
Attachable? Non-attachable Non-attachable Attachable unit Attachable unit
Usage Designed for PoE
1
modules, can be used
to power the switch.
Designed for PoE
modules, can be used
to power the switch.
Powers the switch.
Cannot be used to
power PoE modules,
which require 48V DC.
Powers the switch.
Cannot be used to
power PoE modules,
which require 48V DC.
