Cisco IE 3000 Switch Hardware Installation Guide
Chapter 1 Overview
Front-Panel Description
Figure 1-12 LEDs on the Cisco IEM-3000-8FM Module
Figure 1-13 LEDs on the Cisco IEM-3000-8SM Module
Note The port numbering sequence is the same for the IEM-3000-4SM expansion module.
1 100BASE -FX port LEDs
1
201705
1 100BASE-X port LEDs
1
5
2
6
3
7
4
8
