Cisco IE 3000 Hardware Installation Guide

1-14
Cisco IE 3000 Switch Hardware Installation Guide
Chapter 1 Overview
Front-Panel Description
The LED arrangement on the IEM-3000-4PC PoE expansion module is similar to the LED arrangement
on the IEM-3000-4PC-4TC PoE expansion module except that the IEM-3000-4PC module does not have
the four additional non-PoE ports with their associated port LEDs.
Setup LED
The Setup LED displays the express setup mode for the initial configuration. Table 1-3 lists the LED
colors and their meanings.
System LED
The System LED shows whether the system is receiving power and is functioning properly.
Table 1-4 lists the system LED colors and their meanings.
Alarm LED
Table 1-5 lists the alarm LED colors and their meanings.
Ta b l e 1- 3 S e t u p L E D
Color Setup Status
Off (dark) Switch is configured as a managed switch.
Solid green Switch is in initial setup.
Blinking green Switch is in initial setup, in recovery, or initial setup is
incomplete.
Solid
red Switch failed to start initial setup or recovery because
there is no available switch port to which to connect the
management station. Disconnect a device from a switch
port, and then press the Express Setup button.
Ta b l e 1- 4 S y s t e m L E D
Color System Status
Off System is not powered on.
Green System is operating normally.
Red Switch is not functioning properly.
Table 1-5 Alarm Status LED
Color System Status
Off Alarms are not configured, or the switch is off.
Green Alarms are configured.
Blinking red Switch has detected a major alarm.
Red Switch has detected a minor alarm.
