Cisco Meraki MS225 Series User Manual

7. (Optional) Install additional SFP+, QSFP+ or QSFP28 units as needed, depending on the compatibility of your model.
Mounting hardware
The mounting hardware includes a rack mount kit for standard 1U racks. When installing the device, make sure that
there is sufficient space between the rear of the rack and other obstacles to ensure adequate airflow.
Optional Mid-Mount bracket
MS225 48 port models are designed for an optional MA-MNT-MID-1 mid-mount bracket when using 2-post racks.
Basic Troubleshooting
The following steps can be used for troubleshooting basic connectivity issues with your switch.
• Reset the switch
• Factory reset the switch by holding the factory reset button for 5 seconds
• Try switching cables, or testing your cable on another device
If your switch still does not connect, the following link may be useful, depending on your issue: Troubleshooting an MS
13

Cisco Meraki MS225 Series Specifications

General

Model	MS225 Series
Series	MS225
Category	Switch
Stacking	Yes, via Meraki Cloud
Power Supply	Internal
Layer	Layer 2
DRAM	512 MB
Operating Temperature	0°C to 40°C
Uplink	4 x SFP+
Management	Cloud Managed
Switching Capacity	176 Gbps
Forwarding Rate	131 Mpps
Total PoE Budget	740W (MS225-48FP)
Dimensions (W x D x H)	17.3 x 10.2 x 1.7 in (440 x 260 x 44 mm)
Ports	24 x GbE or 48 x GbE
Power over Ethernet (PoE)	802.3af/at (PoE/PoE+)
