Cisco NCS 540 Series Routers

bandwidth remaining
To specify how to allocate leftover bandwidth to various classes, use the bandwidth remaining command
in policy map class configuration mode. To return to the system defaults, use the no form of this command.
bandwidth remaining [{percent percentage-value|ratio ratio-value}]
no bandwidth remaining [{percent percentage-value|ratio ratio-value}]
Syntax Description
Specifies the amount of guaranteed bandwidth, based on an absolute percentage
of the available bandwidth. Range is from 1 to 100.
percent percentage-value
Specifies the amount of guaranteed bandwidth, based on a bandwidth ratio
value. Range is 1 to 2000.
ratio ratio-value
Command Default
No bandwidth is specified.
Command Modes
Policy map class configuration
Command History
ModificationRelease
This command was introduced.Release 6.0
Usage Guidelines
Bandwidth, bandwidth remaining, shaping, queue-limit and WRED commands can be configured together in
the same class.
The bandwidth remaining command is supported only in the egress direction.
Note
The available bandwidth is equally distributed among those queueing classes that do not have the remaining
bandwidth explicitly configured.
The bandwidth remaining command is used to proportionally allocate bandwidth to the particular classes,
but there is no reserved bandwidth capacity.
On egress, if the bandwidth remaining command is not present, then the bandwidth is shared equally among
the configured queueing classes present in the policy-map.
Task ID
OperationsTask
ID
read,
write
qos
Examples
This example shows how the remaining bandwidth is shared by classes class1 and class2 in a 20:80
ratio.
RP/0/RP0/CPU0:router(config)# policy-map policy1
Modular QoS Command Reference for Cisco NCS 5500 Series and Cisco NCS 540 Series Routers
66
Congestion Avoidance Commands
bandwidth remaining
