Cisco IP Phone 8861 and 8865 Wireless LAN Deployment Guide
13
Max Tx Power = 14 dBm
(Depends on region)
6 Mbps
OFDM - BPSK
-94 dBm
9 Mbps
OFDM - BPSK
-93 dBm
12 Mbps
OFDM - QPSK
-92 dBm
18 Mbps
OFDM - QPSK
-89 dBm
24 Mbps
OFDM - 16 QAM
-86 dBm
36 Mbps
OFDM - 16 QAM
-83 dBm
48 Mbps
OFDM - 64 QAM
-78 dBm
54 Mbps
OFDM - 64 QAM
-76 dBm
5 GHz - 802.11n (HT20)
Data Rate
Modulation
Receiver Sensitivity
Max Tx Power = 13 dBm
(Depends on region)
7 Mbps (MCS 0)
OFDM - BPSK
-94 dBm
14 Mbps (MCS 1)
OFDM - QPSK
-91 dBm
21 Mbps (MCS 2)
OFDM - QPSK
-89 dBm
29 Mbps (MCS 3)
OFDM - 16 QAM
-86 dBm
43 Mbps (MCS 4)
OFDM - 16 QAM
-82 dBm
58 Mbps (MCS 5)
OFDM - 64 QAM
-77 dBm
65 Mbps (MCS 6)
OFDM - 64 QAM
-76 dBm
72 Mbps (MCS 7)
OFDM - 64 QAM
-74 dBm
5 GHz - 802.11n (HT40)
Data Rate
Modulation
Receiver Sensitivity
Max Tx Power = 13 dBm
(Depends on region)
15 Mbps (MCS 0)
OFDM - BPSK
-91 dBm
30 Mbps (MCS 1)
OFDM - QPSK
-88 dBm
45 Mbps (MCS 2)
OFDM - QPSK
-86 dBm
60 Mbps (MCS 3)
OFDM - 16 QAM
-83 dBm
90 Mbps (MCS 4)
OFDM - 16 QAM
-79 dBm
120 Mbps (MCS 5)
OFDM - 64 QAM
-75 dBm
135 Mbps (MCS 6)
OFDM - 64 QAM
-73 dBm
150 Mbps (MCS 7)
OFDM - 64 QAM
-72 dBm
5 GHz - 802.11ac (VHT20)
Data Rate
Modulation
Receiver Sensitivity
Max Tx Power = 12 dBm
(Depends on region)
7 Mbps (MCS 0)
OFDM - BPSK
-93 dBm
14 Mbps (MCS 1)
OFDM - QPSK
-90 dBm
21 Mbps (MCS 2)
OFDM - QPSK
-87 dBm
29 Mbps (MCS 3)
OFDM - 16 QAM
-84 dBm
43 Mbps (MCS 4)
OFDM - 16 QAM
-81 dBm
58 Mbps (MCS 5)
OFDM - 64 QAM
-76 dBm
65 Mbps (MCS 6)
OFDM - 64 QAM
-75 dBm
72 Mbps (MCS 7)
OFDM - 64 QAM
-74 dBm
87 Mbps (MCS 8)
OFDM – 256 QAM
-70 dBm
5 GHz - 802.11ac (VHT40)
Data Rate
Modulation
Receiver Sensitivity
Max Tx Power = 12 dBm
(Depends on region)
15 Mbps (MCS 0)
OFDM - BPSK
-90 dBm
30 Mbps (MCS 1)
OFDM - QPSK
-87 dBm
45 Mbps (MCS 2)
OFDM - QPSK
-85 dBm
60 Mbps (MCS 3)
OFDM - 16 QAM
-82 dBm
