Page #134 background image
Cisco IP Phone 8861 and 8865 Wireless LAN Deployment Guide
134
FROM RECEIVING INBOUND CALLS. BY SELECTING THIS MODE, YOU
AGREE TO THE FOLLOWING: (I) YOU ARE TAKING FULL
RESPONSIBILITY FOR PROVIDING ALTERNATE METHODS FOR
EMERGENCY CALLING AND RECEIVING CALLS WHILE THE MODE IS
IN EFFECT; (II) CISCO HAS NO LIABILITY IN CONNECTION WITH
YOUR SELECTION OF THE MODE AND ALL LIABILITY IN
CONNECTION WITH ENABLING THE MODE IS YOUR
RESPONSIBILITY; AND (III) YOU WILL FULLY INFORM USERS OF THE
EFFECTS OF THE MODE ON CALLS, CALLING AND OTHERWISE.
Phone On Time
This field determines the time that the phone turns on automatically on the days
that are selected in the Enable Power Save Plus list box. Enter the time in 24 hour
format, where 00:00 represents midnight. For example, to automatically turn the
phone on at 7:00 a.m., (0700), enter 07:00. To turn the phone on at 2:00 p.m.
(1400), enter 14:00. If this field is blank, the phone automatically turns on at
00:00. The default is blank.
Phone Off Time
This field determines the time of day that the phone will turn itself off on the days
that are selected in the Enable Power Save Plus list box. Enter the time in the
following format hours:minutes. If this field is blank, the phone automatically
turns off at midnight (00:00). The default is blank. Note: If Phone On Time is
blank (or 00:00) and Phone Off Time is blank (or 24:00), the phone will remain
on continuously, effectively disabling the Power Save Plus feature unless you
allow EnergyWise to send overrides.
Phone Off Idle Timeout
This field represents the number of minutes that the device must be idle before
the device will request the power sourcing equipment (PSE) to power down the
device. The value in this field takes effect: - When the device was in Power Save
Plus mode as scheduled and was taken out of Power Save Plus mode because the
phone user pressed the select key - When the phone is repowered by the attached
switch - When the Phone Off Time is met but the phone is in use The unit is
minutes. The default is 60. The range is 20 to 1440.
Enable Audible Alert
This checkbox, when enabled, instructs the phone to play an audible alert ten
minutes prior to the time specified in the field, Phone Off Time. The select key
on the phone will quickly flash to visually alert the user to the impending phone
state change (powering off as a result of the Power Save Plus feature). To also
audibly alert the user, enable this checkbox. The default is disabled. This
checkbox only applies if the Enable Power Save Plus list box has one or more
days selected.
EnergyWise Domain
This field defines the EnergyWise domain in which the phone is participating. An
EnergyWise domain is required by the Power Save Plus feature. If you have
chosen days in the Enable Power Save Plus list box, you must also provide an
EnergyWise domain. The default is blank.
EnergyWise Secret
This field defines the password (shared secret) used to communicate within the
EnergyWise domain. An EnergyWise domain and secret is required by the Power
Save Plus feature. If you have chosen days in the Enable Power Save Plus list
box, you must also provide an EnergyWise domain and secret. The default is
blank. Note: The Power Save Plus behavior is different for TNP and Roundtable
devices. For TNP, the device is completely turned off, no illuminated key. For
Roundtable, the power sourcing equipment (PSE) provides minimal power to
illuminate the select key. The following table explains the Unified CM
Administration product specific configuration fields that enable and configure
Power Save Plus mode, and the help text for each field. Table: Unified CM
Administration Configuration Fields for Power Save Plus Field Label Help Text
