Enable LED5Main 0 Antenna1
SIM 0 LED6Diversity 1 Antenna2
SIM 1 LED7Diversity 0 Antenna3
RSSI LEDs8Main 1 Antenna4
P-LTEAP18-GL Frequency Bands
The following table provides the global frequency bands available.
Antennas must be attached to the RF connectors as listed below for proper bands service.
Note
DescriptionItem
B1, B2(B25), B3, B4(B66), B5(B26,B18,B19), B8, B12(B17), B13, B14, B20, B28,
B29, B39, B71, B41
MAIN 0 and DIV 0
B7, B30, B32, B38, B40, B41, B42, B46, B48, B2(B25)MAIN 1 and DIV 1
5G Pluggable Interface Module
The 5G Sub-6 GHz Pluggable Interface Module offers 5G capability to the IoT Industrial Router family. The
product ID for the pluggable module is P-5GS6-GL. The P-5GS6-GL uses the FN980 Telit modem.
IOS XE release 17.8.1 is the first software release to provide support for the P-5GS6-GL on IR8340 router.
Note
The following features and limitations apply across all IoT routing platforms unless specifically mentioned:
• IoT routing platforms support a maximum of two pluggable modules, with a combination of 5G and 4G
PIMs.
• The pluggable module can be started or stopped through the CLI under exec mode. Also, it can be
configured to power off the module to reduce power consumption as needed.
• The capability to disable FDD Band 30 for vehicular applications is available.
The following figure shows the P-5GS6-GL pluggable module:
Cisco Catalyst IR8340 Rugged Series Router Hardware Installation Guide
9
Product Overview
P-LTEAP18-GL Frequency Bands
