A-1
Cisco Nexus 2000 Series Hardware Installation Guide
OL-19013-05
APPENDIX
A
Cabinet and Rack Installation
This appendix provides the requirements for cabinet and rack installation and includes the following
sections:
• Cabinet and Rack Requirements, page A-1
• Cable Management Guidelines, page A-3
Cabinet and Rack Requirements
This section provides the requirements for the following types of cabinets and racks, assuming an
external ambient air temperature range of 0 to 104
o
F (0 to 40
o
C):
• Standard perforated cabinets
• Solid-walled cabinets with a roof fan tray (bottom to top cooling)
• Standard open racks
Note If you are selecting an enclosed cabinet, we recommend one of the thermally validated types, either
standard perforated or solid-walled with a fan tray.
Note Do not use racks that have obstructions (such as power strips), because the obstructions could impair
access to field-replaceable units (FRUs).
This section includes the following topics:
• General Requirements for Cabinets and Racks, page A-1
• Requirements Specific to Perforated Cabinets, page A-2
• Requirements Specific to Standard Open Racks, page A-2
General Requirements for Cabinets and Racks
The cabinet or rack must be one of the following types:
• Standard 19-in. (48.3 cm) (four-post EIA cabinet or rack, with mounting rails that conform to
English universal hole spacing per section 1 of ANSI/EIA-310-D-1992). See the “Requirements
Specific to Perforated Cabinets” section on page A-2.
