B-6
Cisco Nexus 2000 Series Hardware Installation Guide
OL-19013-05
Appendix B Technical Specifications
Transceiver Specifications
Transceiver Specifications
This section describes the transceiver specifications for the Cisco Nexus 2000 Series FEX. This section
includes the following topics:
• SFP+ Optical Transceiver Specifications, page B-6
SFP+ Optical Transceiver Specifications
This section provides the general and environmental specifications for the SFP+ transceivers used with
optical cables.
For the general specifications that apply to SFP+ transceivers, see Table B-4. For the environmental
specifications, see Table B-5.
Table B-4 SFP+ Transceiver General Specifications
Transceiver Cable Type Connector Type Wavelength (nm)
Core Size
(microns)
Modal Bandwidth
(MHz-km)
Maximum Cable
Distance
N2200 FET MMF Dual LC/PC 850 50
50
500
2000
82 feet (25 meters)
328 feet (100 meters)
SFP-10G-SR MMF Dual LC/PC 850 62.5
62.5
50.0
50.0
50.0
160
200
400
500
2000
85 feet (26 meters)
108 feet (33 meters)
216 feet (66 meters)
269 feet (82 meters)
984 feet (984 meters)
SFP-10G-LR SMF Dual LC/PC 1310 G.652 fiber — 6.2 miles (10 km)
Table B-5 Environmental and Power Specifications for the 10-Gbps SFP+ Optical Transceivers
Parameter
1
1. Absolute maximum ratings are those values beyond which damage to
the device may occur if these limits are exceeded for other than a short
period of time.
Specification
Storage temperature –40 to 185°F (–40 to 85°C)
Case temperature
2
2. Functional performance is not intended, device reliability is not
implied, and damage to the device may occur over an extended period
of time between absolute maximum ratings and the recommended
operating conditions.
32 to 158°F (0 to 70°C)
Relative humidity 5 to 95%
Module supply voltage 3.1 to 3.5 V
