1-36
Cisco Nexus 2000 Series Hardware Installation Guide
OL-19013-05
Chapter 1 Using a Fabric Extender with a Cisco Nexus 5000 Series Switch
Cisco Nexus 2148T
Figure 1-33 Blank Power Supply Filler Panel
Fan Tray
The Cisco Nexus 2148T FEX has one fan tray that has front-to-back airflow. Figure 1-34 shows the fan
tray. The fan tray is hot-swappable as long as you replace it within 60 seconds.
Figure 1-34 Front-to-Back Airflow Fan Tray for Cisco Nexus 2148T FEX
2
1
239290
1 Handle 2 Ejector latch
3
2
1
1
239291
