1-28
Cisco Nexus 2000 Series Hardware Installation Guide
OL-19013-05
Chapter 1 Using a Fabric Extender with a Cisco Nexus 5000 Series Switch
Cisco Nexus 2232PP
Supported SFP+ Transceivers
The Cisco Nexus 2232PP Series FEX supports SFP+ Ethernet transceivers. This section includes the
following topics:
• SFP Transceivers, page 1-37
• SFP+ Copper Cables, page 1-37
SFP+ Transceivers
The enhanced Small-Form-Factor Pluggable (SFP+) 10-Gigabit Ethernet transceiver is a bidirectional
device with a transmitter and receiver. It has a 20-pin connector on the electrical interface and duplex
LC connector on the optical interface. Currently, the Cisco Nexus 2000 Series FEX supports the
short-range SFP and long-range SFP transceiver. Table 1-15 describes the SFP+ transceivers used with
the Cisco Nexus 2232PP FEX.
SFP+ Copper Cables
Copper interface cables are available for use with the 10-Gigabit Ethernet SFP+ transceiver. Table 1-16
lists the available cables and provides a brief description of the cables.
Table 1-15 SFP+ Transceivers Used with the Cisco Nexus 2232PP FEX
Model Description
N2200 FET 10-Gigabit Ethernet for connections with a Cisco Nexus 5000 Series switch
SFP-10G-SR 10-Gigabit Ethernet—short range SFP+ module
SFP-10G-LR 10-Gigabit Ethernet—long range SFP+ module
Table 1-16 Copper Cables Used with the Cisco Nexus 2232PP FEX
Model Description
SFP-H10GB-CU1M 10-Gigabit BASE-CU SFP+ Passive Cable
(1 meter)
SFP-H10GB-CU3M 10-Gigabit BASE-CU SFP+ Passive Cable
(3 meters)
SFP-H10GB-CU5M 10-Gigabit BASE-CU SFP+ Passive Cable
(5 meters)
SFP-H10GB-CU7MA 10-Gigabit BASE-CU SFP+ Active Cable
(7 meters)
SFP-H10GB-CU10MA 10-Gigabit BASE-CU SFP+ Active Cable
(10 meters)
