Chapter 1 Using a Fabric Extender with a Cisco Nexus 5000 Series Switch
Cisco Nexus 2224TP
To replace a fan tray, see the “Removing and Installing the Fan Tray” section on page 3-20. For LED
descriptions, see Table D-1 on page D-2.
Supported SFP+ Transceivers
The Cisco Nexus 2224TP FEX supports SFP+ Ethernet transceivers. This section includes the following
topics:
• SFP+ Transceivers, page 1-32
• SFP+ Copper Cables, page 1-32
SFP+ Transceivers
The enhanced Small-Form-Factor Pluggable (SFP+) 10-Gigabit Ethernet transceiver is a bidirectional
device with a transmitter and receiver. It has a 20-pin connector on the electrical interface and duplex
LC connector on the optical interface. Currently, the Cisco Nexus 2224TP FEX supports the short-range
SFP and long-range SFP transceiver. Table 1-19 describes the SFP+ transceivers used with the Cisco
Nexus 2224TP FEX.
SFP+ Copper Cables
Copper interface cables are available for use with the 10-Gigabit Ethernet SFP+ transceiver. Table 1-20
lists the available cables and provides a brief description of the cables.
Table 1-19 SFP+ Transceivers Used with the Cisco Nexus 2224TP FEX
Model Description
N2200 FET 10-Gigabit Ethernet for connections with a Cisco Nexus 5000 Series switch
SFP-10G-SR 10-Gigabit Ethernet—short range SFP+ module
SFP-10G-LR 10-Gigabit Ethernet—long range SFP+ module
Table 1-20 Copper Cables Used with the Cisco Nexus 2224TP FEX
Model Description
SFP-H10GB-CU1M 10-Gigabit BASE-CU SFP+ Passive Cable
(1 meter)
SFP-H10GB-CU3M 10-Gigabit BASE-CU SFP+ Passive Cable
(3 meters)
SFP-H10GB-CU5M 10-Gigabit BASE-CU SFP+ Passive Cable
(5 meters)
SFP-H10GB-CU7MA 10-Gigabit BASE-CU SFP+ Active Cable
(7 meters)
SFP-H10GB-CU10MA 10-Gigabit BASE-CU SFP+ Active Cable
(10 meters)
