B-5
Cisco Nexus 2000 Series Hardware Installation Guide
OL-19013-05
Appendix B Technical Specifications
Physical Specifications
The Cisco Nexus 2232PP, 2232TM, and the Cisco Nexus 2248TP-ETP FEXs can operate from 0 to 40°C
ambient temperature in a horizontal or vertical rack mount configuration. They can withstand a
nonoperational temperature of –25 to 70°C altitude of 10 to 90 percent noncondensing.
Physical Specifications
Table B-3 lists the dimensions and weights for the Cisco Nexus 2000 Series FEXs.
Table B-2 Environmental Specifications for the Cisco Nexus 2000 Series FEX
Description Specification
Temperature, operating 32 to 104°F (0 to 40°C)
Temperature, nonoperating –4 to 158°F (–20 to 70°C)
Humidity (RH), noncondensing 5 to 95%
Altitude 0 to 10000 ft (0 to 3000 m)
Table B-3 Physical Specifications for Installing the Cisco Nexus 2000 Series Fabric Extenders
Cisco Nexus 2000 Series
Dimensions (Height x Width x Depth)
1
Weight
2
Inches Centimeters
Cisco Nexus 2248TP-E
chassis
1.72 x 17.3 x 17.7 in. 4.37 x 43.94 x 44.96 cm 17.7 lb (8.03 kg)
Power supply
Fan tray
—
—
—
—
2.2 lb (1.0 kg)
1.4 lb (0.6 kg)
Cisco Nexus 2248TP chassis 1.72 x 17.3 x 17.7 in. 4.37 x 43.94 x 44.96 cm 17.7 lb (8.03 kg)
Power supply
Fan tray
—
—
—
—
2.2 lb (1.0 kg)
1.4 lb (0.6 kg)
Cisco Nexus 2232PP chassis 1.72 x 17.3 x 17.7 in. 4.37 x 43.94 x 44.96 cm 18.3 lb (8.3 kg)
Power supply
Fan tray
—
—
—
—
2.2 lb (1.0 kg)
1.8 lb (0.8 kg)
Cisco Nexus 2224TP chassis 1.72 x 17.3 x 17.7 in. 4.37 x 43.94 x 44.96 cm 16.6 lb (1.0 kg)
Power supply
Fan tray
—
—
—
—
2.2 lb (1.0 kg)
1.4 lb (0.6 kg)
Cisco Nexus 2148T chassis 1.72 x 17.3 x 20.0 in. 4.37 x 43.94 x 50.8 cm 18.0 lb (8.2 kg)
Power supply
Fan tray
—
—
—
—
1.5 lb (0.7 kg)
1.5 lb (0.7 kg)
Cisco Nexus 2232TM chassis 1.72 x 17.3 x 17.7 in. 4.37 x 43.94 x 44.96 cm 18.5 lb (8.4 kg)
Power supply
Fan tray
—
—
—
—
2.2 lb (1.0 kg)
1.8 lb (0.8 kg)
1. Dimensions are presented for only the chassis rack size and service clearance requirements.
2. Combine the chassis, power supply, and fan tray weights for the overall weight of the switch to be installed. Remember to
double the power supply weights if there are two power supplies installed in the FEX.
