1-5
Cisco Nexus 2000 Series Hardware Installation Guide
OL-19013-05
Chapter 1 Using a Fabric Extender with a Cisco Nexus 5000 Series Switch
Cisco Nexus 2248TP-E
Figure 1-4 AC Power Supply with Back-to-Front Airflow for the Cisco Nexus 2200 Platform
Chassis
Figure 1-5 DC Power Supply for the Cisco Nexus 2200 Platform Chassis
1
3
4
5
239932
A220 P C-400
2
1 Handle 4 Black stripe (back-to-front airflow)
2 FAIL (top) and OK (bottom) LEDs 5 AC power receptacle
3 Ejector latch
1
2
4
3
5
239933
1 Handle 4 Ejector latch
2 FAIL (left) and OK (right) LEDs 5 No black stripe (front-to-back airflow)
3 DC power receptacle
