Cisco SD2008T-NA Installation Guide

2-3
Cisco Nexus 2000 Series Hardware Installation Guide
OL-19013-05
Chapter 2 Using a Fabric Extender with a Cisco Nexus 7000 Series Switch
Cisco Nexus 2248TP-E FEX
Figure 2-1 Front View of the Cisco Nexus 2248TP-E Chassis
The rear of the Cisco Nexus 2248TP-E FEX chassis has 48 100/1000 Ethernet downlink ports, four
10-Gigabit Ethernet uplink ports, an HDMI port, and LEDs, as shown in Figure 2-2.
Figure 2-2 Rear View of the Cisco Nexus 2248TP-E Chassis
2
1
3
4
239288
1 Power supply 3 Power supply (blank shown)
2 Fan tray 4 Status (top) and ID (bottom) LEDs
3
2
4
1
239287
1 Status (top) and ID (bottom) LEDs 3 100/1000 Ethernet host-facing (downlink) ports (48)
2 HDMI port 4 10-Gigabit Ethernet network-facing (uplink) ports (4)

Cisco SD2008T-NA Specifications

General

Brand	Cisco
Model	SD2008T-NA
Category	Extender
Language	English
