Chapter 2 Using a Fabric Extender with a Cisco Nexus 7000 Series Switch
Cisco Nexus 2248TP-E FEX
Figure 2-5 DC Power Supply with Front-to-Back Airflow for the Cisco Nexus 2200 Platform
Figure 2-6 Black Stripe Used to Indicate Back-to-Front Airflow
1 Handle 4 Ejector latch
2 FAIL (left) and OK (right) LEDs 5 No black stripe (front-to-back airflow)
3 DC power connector with safety cover
1 Black stripe (back-to-front airflow)
