Send documentation comments to nexus5kdocs@cisco.com
2-8
Cisco Nexus 2000 Series Hardware Installation Guide
OL-19013-05
Chapter 2 Using a Fabric Extender with a Cisco Nexus 7000 Series Switch
Cisco Nexus 2248TP-E FEX
Figure 2-8 Front-to-Back Airflow Fan Tray for the Cisco Nexus 2000 Series FEX
Figure 2-9 Back-to-Front Airflow Fan Tray for the Cisco Nexus 2000 Series FEX
1 Captive screws (2) 3 Status LED
2 No black stripe on the front indicates that this
fan tray has front-to-back airflow.
