Page #159 background imageLoading...
Page #159 background image
Administration: Discovery
Configuring LLDP
141 Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3
9
STEP 1 Click Administration > Discovery - LLDP > LLDP Statistics.
For each port, the fields are displayed:
Interface—Identifier of interface.
Tx Frames Total—Number of transmitted frames.
Rx Frames
-
To t a l
—Number of received frames.
-
Discarded
Total number of received frames that were discarded.
-
Errors
Total number of received frames with errors.
Rx TLVs
-
Discarded
Total number of received TLVs that were discarded.
-
Unrecognized
Total number of received TLVs that were unrecognized.
Neighbor’s Information Deletion Count—Number of neighbor ageouts on
the interface.
STEP 2 Click Refresh to view the latest statistics.
LLDP Overloading
LLDP adds information as LLDP and LLDP-MED TLVs into the LLDP packets. LLDP
overload occurs when the total amount of information to be included in a LLDP
packet exceed the maximum PDU size supported by an interface.
The LLDP Overloading page
displays the number of bytes of LLDP/LLDP-MED
information, the number of available bytes for additional LLDP information, and the
overloading status of every interface.
To view LLDP overloading information:
STEP 1 Click Administration > Discovery - LLDP > LLDP Overloading.
This page contains the following fields for each port:
Interface—Port identifier.
Total (By te s)Total number of bytes of LLDP information in each packet
