Cisco SG500-52P Administration Guide

IP Configuration: RIPv2
Configuring RIP
Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3 352
18
Creating an Access List
To set the global configuration of an access list.
STEP 1 Click IP Configuration > Access List > Access List Settings.
STEP 2 To add a new Access List, click Add to open the Add Access List page and enter
the following fields:
• Name—Define a name for the access list.
• Source IPv4 Address—Enter the source IPv4 address. The following
options are available:
- Any—All IP addresses are included.
- User Defined—Enter an IP address.
• Source IPv4 Mask—Enter the source IPv4 address mask type and value.
The following options are available:
- Network Mask—Enter the network mask.
- Prefix Length—Enter the prefix length.
• Action—Select an action for the access list. The following options are
available:
- Permit—Permit entry of packets from the IP address(es) in the access
list.
- Deny—Reject entry of packets from the IP address(es) in the access list.
Populate an Access List
To populate an access list with IP addresses.
STEP 1 Click IP Configuration > Access List > Source IPv4 Address List.
STEP 2 To modify the parameters of an access list, click Add to open the Edit Access List
page and modify any of the following fields:
• Access List Name—Name of the access list.
• Source IPv4 Address—Source IPv4 address. The following options are
available:

Cisco SG500-52P Specifications

General

Model	SG500-52P
Ports	52
PoE Ports	48
PoE+	Yes
Switching Capacity	104 Gbps
Layer	Layer 3
Power over Ethernet (PoE)	Yes
Rack Mountable	Yes
VLAN Support	Yes
Manageable	Yes
Jumbo Frame Support	Yes
Power Supply	Internal
Dimensions	440 x 44 x 350 mm
MAC Address Table Size	16K entries
Operating Temperature	0°C to 50°C
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90%, non-condensing
