VLAN Management
VLAN Groups
Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3 224
13
• GVRP Registration—Select to enable VLAN Registration using GVRP on
this interface.
STEP 7 Click Apply. GVRP settings are modified, and written to the Running Configuration
file.
VLAN Groups
VLAN groups are used for load balancing of traffic on a Layer 2 network.
Packets are assigned a VLAN according to various classifications that have been
configured (such as VLAN groups).
If several classifications schemes are defined, packets are assigned to a VLAN in
the following order:
• TA G: If the packet is tagged, the VLAN is taken from the tag.
• MAC-Based VLAN: If a MAC-based VLAN has been defined, the VLAN is
taken from the source MAC-to-VLAN mapping of the ingress interface.
• Protocol-Based VLAN: If a protocol-based VLAN has been defined, the
VLAN is taken from the (Ethernet type) protocol-to-VLAN mapping of the
ingress interface.
• PVID: VLAN is taken from the port default VLAN ID.
MAC-based Groups
MAC-based VLAN classification enable packets to be classified according to their
source MAC address. You can then define MAC-to-VLAN mapping per interface.
You can define several MAC-based VLAN groups, which each group containing
different MAC addresses.
These MAC-based groups can be assigned to specific ports/LAGs. MAC-based
VLAN groups cannot contain overlapping ranges of MAC addresses on the same
port.
Workflow
To define a MAC-based VLAN group:
