Cisco SG500-52P Administration Guide

VLAN Management
Creating VLANs
217 Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3
13
• Default VLAN ID After Reboot—Enter a new VLAN ID to replace the default
VLAN ID after reboot.
STEP 3 Click Apply.
STEP 4 Click Save (in the upper-right corner of the window) and save the Running
Configuration to the Startup Configuration.
The Default VLAN ID After Reset becomes the Current Default VLAN ID after
you reboot the device.
Creating VLANs
You can create a VLAN, but this has no effect until the VLAN is attached to at least
one port, either manually or dynamically. Ports must always belong to one or more
VLANs.
Each VLAN must be configured with a unique VID (VLAN ID) with a value from
1 to 4094. The device reserves VID 4095 as the Discard VLAN. All packets
classified to the Discard VLAN are discarded at ingress, and are not forwarded to
a port.
To c r e a t e a V L A N :
STEP 1 Click VLAN Management > Create VLAN.
The Create VLAN page contains the following fields for all VLANs:
• VLAN ID—User-defined VLAN ID.
• VLAN Name—User-defined VLAN name.
• Type—VLAN type:
- Dynamic—VLAN was dynamically created through Generic VLAN
Registration Protocol (GVRP).
- Static—VLAN is user-defined.
- Default—VLAN is the default VLAN.
STEP 2 Click Add to add a new VLAN or select an existing VLAN and click Edit to modify
the VLAN parameters.

Cisco SG500-52P Specifications

General

Model	SG500-52P
Ports	52
PoE Ports	48
PoE+	Yes
Switching Capacity	104 Gbps
Layer	Layer 3
Power over Ethernet (PoE)	Yes
Rack Mountable	Yes
VLAN Support	Yes
Manageable	Yes
Jumbo Frame Support	Yes
Power Supply	Internal
Dimensions	440 x 44 x 350 mm
MAC Address Table Size	16K entries
Operating Temperature	0°C to 50°C
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90%, non-condensing
