Cisco SG500-52P Administration Guide

IP Configuration
DHCP Server
Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3 308
17
The following options can be set with the generic DHCP option CLI command:
• Integer type: 2, 13, 22, 26, 24, 25, 35, 38
• ASCII type: 14, 17, 18, 40, 43, 47, 64
• IP Address type: 16, 28, 32
• IP List type: 5, 7-11, 21, 33, 41, 42, 45, 48, 49, 65, 69-76
The following table defines DHCP options which are supported by the DHCPv4
server, but cannot be set in the GUI or CLI:
51 Extension IP Address Lease Time
44 NetBIOS NetBIOS over TCP/IP Name Server Option
netbios-name-server
46 NetBIOS NetBIOS over TCP/IP Node Type Option
netbios-node-type
Option # Option Name Description
50 Requested IP
Address
The option is created by the DHCP client during
renew
53 DHCP Message
Type
The option specifies the DHCP message type
(value - message type):
• 1 - DHCPDISCOVER
• 2 - DHCPOFFER
• 3 - DHCPREQUEST
• 4 - DHCPDECLINE
• 5 - DHCPACK
• 6 - DHCPNAK
• 7 - DHCPRELEASE
• 8 - DHCPINFORM
54 Server Identifier This option, created by the DHCP client, is the
IP address of the selected server.

Cisco SG500-52P Specifications

General

Model	SG500-52P
Ports	52
PoE Ports	48
PoE+	Yes
Switching Capacity	104 Gbps
Layer	Layer 3
Power over Ethernet (PoE)	Yes
Rack Mountable	Yes
VLAN Support	Yes
Manageable	Yes
Jumbo Frame Support	Yes
Power Supply	Internal
Dimensions	440 x 44 x 350 mm
MAC Address Table Size	16K entries
Operating Temperature	0°C to 50°C
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90%, non-condensing
