Cisco SG500-52P Administration Guide

Quality of Service
Managing QoS Statistics
Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3 508
25
- Set 1—Displays the statistics for Set 1 that contains all interfaces and
queues with a high DP (Drop Precedence).
- Set 2—Displays the statistics for Set 2 that contains all interfaces and
queues with a low DP.
• Interface—Select the ports for which statistics are displayed. The options
are:
-
Unit No —Selects the unit number.
- Port—Selects the port on the selected unit number for which statistics
are displayed.
- All Ports—Specifies that statistics are displayed for all ports.
• Queue—Select the queue for which statistics are displayed.
• Drop Precedence—Enter drop precedence that indicates the probability of
being dropped.
STEP 6 Click Apply. The Queue Statistics counter is added, and the Running Configuration
file is updated.

Cisco SG500-52P Specifications

General

Model	SG500-52P
Ports	52
PoE Ports	48
PoE+	Yes
Switching Capacity	104 Gbps
Layer	Layer 3
Power over Ethernet (PoE)	Yes
Rack Mountable	Yes
VLAN Support	Yes
Manageable	Yes
Jumbo Frame Support	Yes
Power Supply	Internal
Dimensions	440 x 44 x 350 mm
MAC Address Table Size	16K entries
Operating Temperature	0°C to 50°C
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90%, non-condensing
