Installing Your Phone
(Optional) Mounting Your Cisco SPA 303 Phone to the Wall
Cisco Small Business IP Phone SPA 303 User Guide (SIP) 22
2
Reversing the Handset Retention Tab
If you mount the phone to a vertical surface, you must reverse the handset retention tab on the
phone body so that the handset does not fall off the phone when it is placed on the cradle.
Figure 3 Handset Retention Tab (Default Position)
STEP 1 Insert a coin or object of similar width into the slot.
STEP 2 Rotate the tab180°. (See Figure 4.) The tab now catches the slot in the handset when the
handset is placed onto the cradle.
