SpecificationDescription
2790 VA @ 200 VACMaximum Input VA
2500 W (up to four power supplies)Maximum output power per power supply
35 A (sub cycle duration)Maximum inrush current
8530 BTUMaximum Heat Output
12 ms @ 2500 WMaximum hold up time
12 VDC @ 208 APower supply output voltage
3.3 VDC @ 5APower supply standby voltage
Climate Savers PlatinumEfficiency Rating
20% 50% 100%
90% 94% 91%
Efficiency (80 Plus Platinum Certified)
IEC320 C20Input connector
Table 21: DC-Input Power Supply (UCSB-PSU-2500DC48) Specifications
SpecificationItem
Cisco UCS Software Release 2.0(1)
Capability Catalog Version 42
Minimum software requirement
–48 VDC to –60 VDC nominal
(range: -40 VDC to -72 VDC)
DC-input voltage
2500 WMaximum output power
90 A (cold turn-on)Maximum inrush current
71 ACurrent draw at min voltage
40 ACurrent draw at max voltage
2840 WMaximum input VA
88% at 10% load
88% at 20% load
92% at 50% load
88% at 100% load
Efficiency
Cisco UCS 5108 Server Chassis Installation Guide
89
Technical Specifications
Specifications for the Cisco UCS 5108 Blade Server Chassis Power Supply Units
