Migrating IO Modules
The following steps apply when migrating from a Cisco UCS 2204 or UCS 2208 IOM to a Cisco UCS 2304
IOM.
If the primary and the subordinate IOMs are different models—Cisco UCS 2204, UCS 2208, or UCS
2304—the overall status of the IOMs is shown as Peer Comm Problem. However, the IOMs can still be
replaced.
Note
Procedure
Step 1
Remove the configuration on the server ports that are connected to the Cisco UCS 2204 or UCS 2208 IOM
in the subordinate fabric interconnect.
Step 2
Remove the cables and replace the Cisco UCS 2204 or UCS 2208 IOM with the Cisco UCS 2304 IOM in the
chassis.
Step 3
Connect the 40-Gbps cables to the UCS 2304 IOM and the UCS 6332 Fabric Interconnect.
Step 4
Configure the ports as server ports.
Step 5
Wait for Auto Upgrade to complete in the IOM.
Migrating FEX Modules
The following steps describe how to migrate from a Cisco Nexus 2232PP FEX to a Cisco Nexus 2348UPQ
FEX.
The Cisco Nexus 2232PP FEX has 10-Gbps uplink ports. The Cisco Nexus 2348UPQ FEX has 40-Gbps
ports which are supported only by the Cisco UCS 2304 IOM.
Note
Procedure
Step 1
Decommission the existing Cisco Nexus 2232PP FEX.
Step 2
Remove the cables and install the Cisco Nexus 2348UPQ FEX.
Step 3
Connect the cables to the Cisco Nexus 2348UPQ FEX.
Step 4
Wait for Cisco UCS Manager to complete its Discovery and Auto Upgrade of the new FEX module.
Step 5
Reacknowledge all the servers that are connected through the Cisco Nexus 2348UPQ FEX.
Cisco UCS 5108 Server Chassis Installation Guide
81
Installing and Removing Components
Migrating IO Modules
