Cisco UCS 2208XP Installation Guide

from the blade servers in the chassis to the 10-Gigabit Ethernet uplink network ports that connect to the fabric
Interconnect. The IOM can also connect to a peer IOM to form a cluster interconnect.
Figure 13: Cisco UCS 2304 IOM
QSFP port activity LEDs2System status LED1
Captive screws for the insertion latches4HDMI console connector and
Ethernet management port
3
Insertions latches640-Gigabit uplink ports5
40-Gigabit backplane ports7
Cisco UCS 5108 Server Chassis Installation Guide
25
Overview
Cisco UCS 2304 IOM
